GOB front desk LED display – IFM-Desk series, a combination of technology and fashion, is an ideal solution for modern advertising. It is designed for displaying brand logos and dynamic videos, equipped with advanced electronic functions and supports content customization. It is very suitable for corporate reception desks, exhibition booths, conferences, parties, clubs and other scenarios.
The multimedia counter is an innovative solution combining advanced technology with elegant design. With its curved design and high quality, it is very suitable for displaying logos, dynamic video materials and personalized content. It is perfect for corporate reception areas, trade shows, conferences and other activities that require impressive and professional presentations.
GOB front desk curved LED display table that combines technology and fashion, an ideal solution for modern adver-tising. lt is designed for displaying logos and dynamic videos, equipped with advanced electronic functions and supports content customization. Ellipsetable Edge is perfect for corporate receptions, trade show booths, conference events, etc.
High-quality silent wheels, no noise during movement, with positioning and height adjustment functions.
The wheels can also adjust in height. This allows for compensation when the ground is uneven.
Smooth universal wheels allow you to move the screen freely.
Crafted with bendable LED panels for smooth curves and creative shapes-flexibility meets function.
Top 160mm*1920mm, bottom 800mm*1920mm, and support custeom size.
Support remote control from computers, mobile phones, and iPads. support USB, SD, Wi-Fi and 4G transmission methord.
Delivers vibrant, lifelike visuals with dynamic video and image playback.
No need for special installa-tion, just plug in and use.
Comes with sockets to meet diverse power needs. Has a hidden installation for aesthetics and safety, and a well – placed layout for cable management.
Equipped with open compartments and drawers for convenient item storage.
GOB front desk LED display – IFM-Desk series adopts 3840Hz/7680Hz high refresh rate design to provide smooth and flicker-free images. It achieves an excellent 10,000:1 color contrast ratio, far exceeding the typical 5,000:1 contrast ratio of standard black SMD LEDs, bringing amazing color fidelity.
The side -detachable design of the flight case simplifies packing and mobility for our screen, making every move a breeze.
Packed in a flight box, it is im-pact-resistant, waterproof and insulating to ensure the safety of the product during transportation.
With suction tool, front main-tenance becomes very quick and easy.
Application Cases
" Customer Testimonials:
Discover Reiss Display's FP Series fine-pitch LED screen wall, delivering true-to-life images and videos with high-precision pixel pitches. Experience remarkable visual quality and perfect viewing angles. Check out our indoor LED displays and video walls for more info.
Application and Installation Videos
Specifications
|
Item
|
Parameters
|
Parameters
|
Parameters
|
|
Model
|
P1.86 GOB
|
P2 GOB
|
P2.5GOB
|
|
Pixel Pitch(mm)
|
1.86
|
2
|
2.5
|
|
Physical Density (dot/sqm)
|
532512
|
460800
|
294912
|
|
LED Configuration
|
1RGB
|
1RGB
|
1RGB
|
|
LED Type
|
GOB
|
GOB
|
GOB
|
|
Module Size (mmxmm)
|
320×160
|
320×160
|
320×160
|
|
Module Resolution (PXxPX)
|
172×86
|
160×80
|
128×64
|
|
Brightness(cd/sqm)
|
1000-1100
|
1000-1100
|
1000-1050
|
|
Refresh Rate(Hz)
|
3840z
|
3840z
|
3840z
|
|
Drive Mode
|
Constant Current Drive
|
Constant Current Drive
|
Constant Current Drive
|
|
Horizontal Viewing Angle(Deg)
|
170
|
170
|
170
|
|
Vertical Viewing Angle(Deg)
|
170
|
170
|
170
|
|
Cabinet Resolution(PXxPX)
|
1032×516
|
960×480
|
768×384
|
|
Cabinet Max Power Consumption(w)
|
700
|
700
|
700
|
|
Cabinet Average Power Consumption(w)
|
600
|
600
|
600
|
|
Cabinet Size(mmxmm)
|
1065x585x1100
|
1065x585x1100
|
1065x585x1100
|
|
Cabinet Thickness(mm)
|
60mm
|
60mm
|
60mm
|
|
Cabinet Material
|
Die-casting Aluminum
|
Die-casting Aluminum
|
Die-casting Aluminum
|
|
Color(M)
|
16.7
|
16.7
|
16.7
|
|
Input Voltage
|
AC100V-240V +/-10%
|
AC100V-240V +/-10%
|
AC100V-240V +/-10%
|
|
Refresh Frame Frequency(Hz)
|
50-60
|
50-60
|
50-60
|
|
Protection Level
|
IP54
|
IP54
|
IP54
|
|
Working Environment
|
Indoor
|
Indoor
|
Indoor
|
|
Working Temperature(℃)
|
-40℃-60℃
|
-40℃-60℃
|
-40℃-60℃
|
|
Storage Humidity(RH)
|
40%-60%
|
40%-60%
|
40%-60%
|
|
Life Span(H)
|
100,000
|
100,000
|
100,000
|
configuration
