Cube LED Display Screen - IFF-CU Series

Discover stunning visuals with the Cube LED Display Screen. Experience seamless stitching and independent face operation for optimal viewing.

1. Seamless Perfection: Complete seamless splicing, SMD 3-in-1 LED, ultra-wide viewing angle, and superior surface flatness for indoor and outdoor excellence.

2. 360° Immersion: Captivating 360° full-angle playback, rotatable along the axis, showcasing personality and delivering exceptional visual appreciation.

3. Creative Customization: Uniquely integrated cube structure, flexible installation, aluminum construction for high heat dissipation, and expertly packaged for safe transport.

4. Efficient Reliability: High efficiency, stability, resolution, pixel density, and uniform color reproduction for clear, sharp, and stunning visuals.

Quick Request
Appointment customization

Your current location:

LED cube display is a 3D visual technology that combines multiple LED panels together to form a cube structure. It is usually composed of 4, 5 or 6 sides, each of which is capable of displaying high-resolution content. These displays utilize light-emitting diodes (LEDs) to create vibrant, dynamic images and videos visible from multiple angles.

In addition, each face of the cube can be operated independently to display different content or work together to present a unified image. These displays are available in a variety of sizes and pixel pitches, suitable for indoor and outdoor environments.

Unlock the Future of Immersive Visuals with Our Captivating LED Cube Displays.

1. SMD Technology: Utilizes surface mount device (SMD) LEDs to achieve superior performance.
2. Pixel Resolution: 2mm, 2.5mm, 4mm, 3mm, 5mm pixel pitches are available.
3. Seamless Edge Stitching: Perfect right-angle edges for excellent visual performance.
4. Multiple Sizes: 320*320mm, 480mm*480mm, 500*500mm, 512*512mm, 640*640mm, support customized sizes.
5. Multiple Types: Support indoor and outdoor.
6. Easy Control Methods: Support multiple control methods for fast content updates.
7.Wide viewing angle: multiple angles without loss of color or clarityy.

Excellent Performance

Immerse yourself in a captivating visual experience with REISSDSPLAY 7680Hz display, delivering unparalleled clarity and seamless motion.
rental led wall

Cabinet Specifications

Each side can be made into a square screen according to the module size, 4 sides, 5 sides, 6 sides are optional

Regular size: 320*320mm/384*384mm/480*480mm/500*500mm/512*512mm576*576mm/640*640mm can be customized according to different size requirements
Module size: 3250*160mm/256*128mm/160*160mm/192*192mm/250*250mmSelect the module size according to the cabinet size

led rental board

Excellent Performance

The spherical LED display has the advantages of light weight, good wind resistance, easy installation, good heat dissipation, convenient front and rear maintenance, good waterproof performance, good earthquake resistance, low cost of auxiliary mounting frame, silent, etc. Similarly, the all-aluminum structure design is light weight and sturdy structure. The spherical LED display adopts trapezoidal line design, which can achieve seamless splicing.
led Stage board

Seamless Splicing

Display module using 45 °beveled edge kit bottom shell, more tightly spliced, fit gap smaller frame using iron cold rolled plate structure design, more solid, not easy to deformation. Supports Front maintenance

led stage screen

High-resolution LED Cubes

The display effect is dynamic and fashionable. The cool cube-shaped display adds a fashionable atmosphere and attracts more attention to your venue.

Multiple Control Methods

Leverage Ethernet, Wi-Fi, 4G/5G or USB interfaces for real-time content updates and management. Allows flexible synchronization of video presentations or asynchronous content on different display surfaces.

360° Viewing Angle

Can be observed from 360 “can feel good visual effect playback video, do not miss any exciting moments

Optionalnumber of Display Surfaces

LED cube display is a 3D visual technology that combines multiple LED panels together to form a cube structure. It usually consists of 4, 5 or 6 sides, each capable of displaying high-resolution content. Each face of the cube can be operated independently to display different content or collaborate to present a unified image.

Creative Custom

Widely used in museums, planetariums, exhibition halls, stadiums, airports, hotels, railway stations, shopping malls, bars, etc.

Is A Cube LED Display Easy To Install And Maintain?

Easy And Fast Installation, Strong Applicability. Floor-standing, wall-mounted, hanging, etc.
Of course. Free tool assembly and replacement. Modular and magnetic design allows for easy assembly and reconfiguration, enabling you to create custom sizes and shapes to fit your unique display needs. Seemlessly expand your display area by adding more cubes, scaling up to massive visual walls for grand events or exhibitions.

Application Cases

How to Clean Your LED Screen?

How to Clean Your LED Screen?

" Customer Testimonials:

How to Clean an LED Screen? Cleaning an LED screen is relatively easy, but you do need to take a few precautions to avoid harming your electronics. Start by finding the right cloths and cleaners, and then gently wipe down your screen, starting with a dry cloth. Also, make sure to avoid certain cleaners so […]

Application and Installation Videos

No videos available.

Specifiche

Model
Application
Number of display surfaces
Resolution
Screen size
Weight
Volume
P2.5
Al chiuso
5
128*128
320*320*320mm
8kg
0.03
P2.5
Al chiuso
4
128*128
320*320*320mm
7kg
0.03
P2.5
Al chiuso
5
192*192
480*480*480mm
14kg
0.11
P2.5
Al chiuso
4
192*192
480*480*480mm
13kg
0.11
P3
Al chiuso
5
128*128
384*384*384mm
12kg
0.05
P3
Al chiuso
4
128*128
384*384*384mm
11kg
0.05
P3
Al chiuso
5
192*192
576*576*576mm
17kg
0.19
P3
Al chiuso
4
192*192
576*576*576mm
16kg
0.19
P3.91
Al chiuso
4
128*128
500*500*500mm
15kg
0.12
P3.91
Al chiuso
5
128*128
500*500*500mm
16kg
0.12
P4
Al chiuso
5
128*128
512*512*512mm
17kg
0.14
P4
Al chiuso
4
128*128
512*512*512mm
16kg
0.14

configuration
