Shape Transparent LED Screen technology delivers groundbreaking 85% transparency with customizable designs for 2024 installations. These Creative Transparent LED Display Solutions achieve 78% higher visual engagement through certified testing. Our Advanced Transparent LED Screen Design Technology has transformed 300+ retail spaces worldwide, setting new standards in architectural integration
REISSDSPLAY TIT-TF Series Transparent LED Display is a cutting-edge display solution, often referred to as a see-through LED display, offering high transparency and brightness. creating transparent LED video walls, making it a powerful tool for transparent glass window advertising, blending digital content seamlessly with the physical space.
Zobrazit podrobnosti
Upto Upto 7680Hz
Wide Viewing Angles
Right Angle Splicing
Ultra thin thickness
Magnetic Suction Installation
Front Maintenance
Aluminum
0.5-75kg/pc
Light transmittance 70%
Brilliant and splendid
Transparent energy saving
High contrast
Ultra light and thin
Adaptable
1000mm ≤25kg/㎡
1000mm*1000mm less than 22kg/㎡
1000*1000mm ≤27kg/㎡
1000*500mm ≤12.5KG
1000mm ≤9.5KG / pcs
1000*500mm 29.5KG / pcs
| Pixel Pitch | P2.84 | P3.91 | P7.81 | P10.42 | P15.625 | P20 |
| Pixel Density(m²） | 56320 | 32768 | 16384 | 9216 | 4096 | 2304 |
| Permeability | 0.56 | 0.7 | 0.56 | 0.65 | 0.75 | 0.85 |
| Refresh Rate(Hz) | ≥3851 | ≥3840 | ≥1920 | ≥1920 | ≥1920 | ≥1920 |
| Cabinet Size(mm) | 1000*500 | |||||
| Cabinet Refresh Rate | 352*80 | 256*64 | 128*64 | 96*48 | 64*32 | 48*24 |
| LED Light | 1415 RGB | 1921 RGB | 1921 RGB | 1921 RGB | 3535 RGB | 3535 RGB |
| Brightness(nits)/㎡ | ≥2700 | ≥4500 | ≥4000 | ≥4000 | ≥4000 | ≥4000 |
| Max Consumption(W/M) | 800 | |||||
| Ave Consumption(W/M) | 240 | 240 | 240 | 200 | 180 | 150 |
| Grey Scale(Bit) | 27 | 16 | 16 | 16 | 16 | 16 |
| Degree protection | IP45 | IP33 | IP33 | IP33 | IP33 | IP33 |
| Weight PC/KG | 5 | 5 | 6 | 6 | 6 | 6 |
| Work Environment | ﹣10℃~51℃ | |||||
| Display Interface | DIV/HDMI | |||||
| Installation Mode | Fixed installation | |||||
| LED Life(h) | 210000 | 100000 | 100000 | 100000 | 100000 | 100000 |
Hanging style
Wall mounted
Column installation
curved wall mounted
Shape Transparent LED Screen solutions deliver factory-direct quality with customizable designs and 85% transparency rates. Our Manufacturing Display Systems ensure premium production standards through Advanced Factory Technology. Direct from our 50,000㎡ production facility, each Shape Transparent LED Solution undergoes rigorous quality control, while Smart Production Integration guarantees consistent performance.
RELSSDISPLAY’s customizable transparent LED displays offer a variety of shapes to suit different design requirements. Whether you need curved, angular, 3D, wall-mounted, hanging, or interactive displays, these options can enhance any environment, making them ideal for retail, exhibitions, corporate spaces, and more. By choosing the right shape, you can create impactful visual experiences that align with your branding and marketing goals.
Installing indoor LED display screens on the wall requires careful planning and execution. Here are the general steps to follow for a successful installation.
The primary advantages of transparent LED display screens are their ability to seamlessly integrate into environments, maintain visual clarity, and create unique visual effects. They allow light and imagery to pass through, making them ideal for applications like storefront windows, architectural installations, and product showcases.
Transparent LED displays are commonly used for digital signage in retail environments, architectural installations like building facades, event and stage setups, product showcases, and even specialized applications like transparent video walls or holographic effects.
When selecting a transparent LED display, key considerations include the intended application, required transparency level, image quality, display size, installation requirements, and budget. Our RELSSDISPLAY experts can guide you through the selection process to identify the optimal solution.
Transparent LED displays from RELSSDISPLAY are designed for long-lasting, reliable performance. With proper maintenance and care, they can operate for 50,000+ hours. Regular cleaning and following the manufacturer’s guidelines help ensure optimal longevity.
RELSSDISPLAY provides a range of advanced features, including remote management capabilities, specialized content management systems, and the ability to create custom transparent display configurations to meet unique project requirements.
